Leírás és Paraméterek
Part No | 90NX0811-M00FT0 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sales Model Name | B1403CVA-S60423 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
EAN Code | 4711387782491 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
UPC Code | 197105782495 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WEEE | 1.04 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BASE UNIT | VSNX0811-BUC105 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Non-preinstalled OS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
LCD cover-material | Plastic | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
LCD cover-color | Gentle Grey | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Top case-material | Plastic | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Top case-color | Gentle Grey | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bottom case-material | Plastic | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bottom case-color | Gentle Grey | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Military grade | US MIL-STD 810H military-grade standard | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Panel Size | 14.0-inch | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backlit | LED Backlit | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Brightness | 300nits | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | FHD (1920 x 1080) 16:9 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Glare | Anti-glare display | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color gamut | NTSC: 45% | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
View angle(H/V) | 170/170 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Response time(Typ/Max) (ms) | 25/35 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Refresh rate | 60Hz | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Contrast (Typ) | 700:1 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Touch Panel | Non-touch screen | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen-to-body ratio | 87 % | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IPS-level | Wide view | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Processor | Intel® Core™ i7-1355U Processor 1.7GHz (12M Cache, up to 5GHz,10 cores) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Chipset | N/A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Discrete/Share | Share | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Integrated GPU | Intel® UHD Graphics | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VRAM | N/A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
How to upgrade memory | Upgradable Need to remove bottom/top case | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Expansion Slot(includes used) | 2x DDR5 SO-DIMM slots 1x M.2 2230 PCIe 4.0x4 1x M.2 2280 PCIe 4.0x4 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
On board memory | N/A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DIMM Memory | 16GB DDR5 SO-DIMM | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Total System Memory | DDR5 16GB | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | 1TB M.2 2280 NVMe™ PCIe® 4.0 SSD | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SSD Cache | N/A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Front-facing camera | 720p HD camera With privacy shutter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless | Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NumberPad | Support NumberPad | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
FingerPrint | N/A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Keyboard type | Backlit Chiclet Keyboard | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
I/O ports | 2x USB 3.2 Gen 1 Type-A 2x USB 3.2 Gen 2 Type-C support display / power delivery 1x HDMI 1.4 1x 3.5mm Combo Audio Jack 1x RJ45 Gigabit Ethernet N/A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio | Audio by Dirac Built-in speaker Built-in array microphone | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Battery | 42WHrs, 3S1P, 3-cell Li-ion | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AC Adapter | TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimension (WxHxD) | 32.45 x 21.44 x 1.97 ~ 1.97 cm (12.78" x 8.44" x 0.78" ~ 0.78") | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight (with Battery) | 1.40 kg (3.09 lbs) // 42 WHrs battery | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight (w/ 2nd Battery) | 1.41 kg (3.11 lbs) // 50 WHrs battery | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight (w/ 3rd Battery) | 1.46 kg (3.22 lbs) // 63 WHrs battery | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight (w/o Battery) | 1.22 kg (2.69 lbs) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Security | Kensington Nano Security Slot™(6x 2.5mm) BIOS Booting User Password Protection BIOS setup user password HDD User Password Protection and Security Support Absolute Persistence 2.0 (Computrace) Trusted Platform Module (TPM) 2.0 N/A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
MyASUS feature | System diagnosis Battery health charging Fan Profile Splendid Tru2Life Function key lock WiFi SmartConnect AppDeals Link to MyASUS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Built-in Apps | MyASUS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Disclaimer for Built-in Apps | Built-in Apps vary from OS SKU. *MyASUS/McAfee don't support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
4G/LTE |
Nincs |
Akkumulátor |
3 cell (42Wh) |
Billentyűzet megvilágítás |
Van |
Bluetooth |
Van |
Dedikált dokkoló |
Nincs |
Dokkolhatóság |
USB porton |
Érintőképernyő (Igen/Nem) |
Nincs |
Felbontás |
1920 x 1080 (FHD1080) 16:9 |
Gyártó |
ASUS |
Háttértár típus |
M.2 SSD |
Képátló |
14 |
Kijelző Típusa |
Matt |
LAN |
10/100/1000 |
Memória. |
16 |
Memória típus |
DDR4 |
Operációs rendszer |
Nincs |
Operációs rendszer verzió |
DOS |
Optikai meghajtó |
Nincs |
Processzor gyártó |
Intel |
Processzor modell |
1355U |
Processzor típus |
Core i7 |
SSD méret |
1024 |
Súly |
1.64 |
Szín |
Szürke |
Terméksorozat |
ExpertBook |
USB 3.1 |
2 |
USB portok száma |
4 |
USB Type-C |
2 |
Video csatlakozás |
HDMI 1.4 |
Videokártya |
Integrált |
Videokártya fajta |
Integrált |
Videokártya típus |
Intel UHD Graphics |
Wireless (Wifi) |
802.11ax |
|
