Leírás és Paraméterek
Specifikációk
Műszaki
| Altitude | 2000 m |
| Auto shutdown function | No |
| Battery management | Replaceable batteries, Automatic battery test, deep-discharge protection, cold-start capable |
| Battery quantity | 1 |
| Battery rating | 12 V / 7 Ah |
| Battery replacement | User replaceable |
| Battery type | Sealed, lead-acid |
| Color | Black |
| Construction type | Free standing model |
| Efficiency | 98 |
| Ethernet interface | No |
| Expansion slots | No |
| Extended battery capability | No |
| Feed type | 1 |
| Form factor | Tower |
| Includes network card | No |
| Input connection | C14 |
| Input cord length | 1.5 m |
| Input frequency range | 46-70 Hz |
| Input nominal voltage | 230V default (220/230/240V) |
| Input voltage - max | 284 |
| Input voltage - min | 161 |
| Input voltage range | 184-264 V (adjustable to 161-284 V) |
| Noise level | <25 dB at 1 meter |
| Nominal frequency | 50/60 Hz |
| Num of Outputs PC (SCHUKO) | 4 |
| Output apparent power | 650 |
| Output frequency | 50/60 Hz |
| Output nominal voltage | 230V default (220/230/240V) |
| Output power factor | 0.6 |
| Output voltage - max | 284 |
| Output voltage - min | 161 |
| Output voltage range | 184-264 V (adjustable to 161-284 V) |
| Package contents | Input cable|User manual|Safety instructions |
| Phase (input) | 1 |
| Phase (output) | 1 |
| Potential free switch contact | No |
| Primary frequency - max | 70 |
| Primary frequency - min | 46 |
| Rack mounting kit | No |
| Receptacle | (3) Schuko, (1) Schuko surge only |
| Relative humidity | 0-85% non-condensing |
| Runtime at full load | 2 min |
| Runtime graph | View runtime graph |
| Secondary frequency - max | 60 |
| Secondary frequency - min | 50 |
| Special features | Convenient extra-flat design for easy installation in any office environment|High performance surge-protection device compliant with IEC 61643-11 standard|Data line protection to ensure that the internet line (including xDSL) is protected against surges|4 outlets to connect your PC + peripherals|Easy to replace battery helps to extend UPS service life |
| Surge protection | Yes |
| Temperature range | 0° to 35°C (32° to 95°F) |
| Topology | Offline |
| Type | UPS |
| Type of interface | None |
| User interface | LEDs |
| VA rating | 650 VA |
| Voltage | 230V |
| Voltage type | AC |
| Wattage | 400W |
Termék méretei
| Hosszúság | 81 MM |
| Szélesség | 235 MM |
| Magasság | 263 MM |
| Mennyiség | 5.006 DMQ |
| Súly | 3.6 KG |
Csomagolás adatai
| Hosszúság | 141 MM |
| Szélesség | 288 MM |
| Magasság | 327 MM |
| Súly | 4.17 KG |
| Gyártó | EATON |
| Kapcsolási mód | Offline |
| Kommunikáció | USB |
| Rack-be szerelhető | Nincs |
| Teljesítmény VA | 650 |
