Leírás és Paraméterek
- Power
-
1200 VA / 720 W
- Type
-
Line Interactive
- Nominal Input Voltage
-
230 VAC
- Nominal Output Voltage
-
230 VAC
- Accepted Input Voltage Range
-
162-290 VAC
- Frequency
-
50 / 60 Hz Auto detection
- Outlets
-
4 x IEC C13 outlets with protection
- Transfer Time to Battery / AC
-
<4ms
- Typical Backup Time
-
25% - 24 min
50% - 11.30 min
75% - 6.35 min
100% - 3 min
- Communication Ports
-
RS232 / USB / Intelligent Port (not included in the package)
- Battery Type
-
Sealed and leak proof maintenance
- Battery Specification
-
12V / 7AH x 2
- Software
-
Monitor & Control over USB, LAN and Internet (SNMP card optional)
- Features
-
Pure sine wave output
Line-interactive
Auto restart
Auto-Charge
Boost and buck AVR for voltage stabilization
Software management
Off-Mode Charging
Cold start function
Emergency power off function (EPO)
Generator Compatible
Smart SNMP card supported
Rack design
- LCD Display
-
Load level, Battery level, AC mode, Battery mode, Bypass mode, Fault indicators
- Environment
-
Humidity: 0-90 % (nin-condensing)
Temperature: 0-40 grades Celsius
Noise level: less than 50 dB
- Physical Dimensions
-
Dimensions: 430 x 438 x 88 mm - 2U Weght: 14.7 kg
| Gyártó | NJOY |
| Kapcsolási mód | Line-interaktiv |
| Kommunikáció | USB+soros |
| Rack-be szerelhető | Nincs |
| Teljesítmény VA | 1200 |
