Leírás és Paraméterek
| Mechanical | |
|---|---|
| Dimensions |
442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72") |
| Weight |
Without Mount: 2.70 kg (5.95 lb) With Mount: 2.79 kg (6.15 lb) |
| Enclosure Material |
SGCC Steel |
| Hardware | |
| Total Non-Blocking Throughput |
26 Gbps |
| Switching Capacity |
52 Gbps |
| Forwarding Rate |
38.69 Mpps |
| Max. Power Consumption |
25W |
| Power Method |
Universal AC Input: 100-240VAC, 50/60 Hz |
| Power Supply |
AC/DC, Internal, 36W |
| Networking Interfaces |
(24) 10/100/1000 Mbps Ethernet RJ45 Ports (2) 1 Gbps SFP Ports |
| Management Interface |
Ethernet In-Band |
| Modes |
SMB Layer 2 Gigabit Ethernet Switch |
| ESD/EMP Protection |
Air: ± 16 kV, Contact: ± 12 kV |
| Operating Temperature |
-5 to 40° C (23 to 104° F) |
| Operating Humidity |
10 - 90% Noncondensing |
| Certifications |
CE, FCC, IC |
| LEDs | |
| System |
(1) Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted |
| Ethernet |
Green: 1G, Amber: 10/100 Mbps |
| SFP |
Green: 1G |
| Gyártó | UBIQUITI |
| Menedzselhető | Van |
| Menedzselhetőség | Web |
| Port típusa | 1Gb Réz |
| Portok száma | 24 |
| Rack-be szerelhető | Van |
| SFP port | 2 |
| Switch típus | Fixed port |
