Leírás és Paraméterek
| Mechanical | |
|---|---|
| Dimensions |
442.4 x 285 x 43.7 mm (17.42 x 11.22 x 1.72") |
| Weight |
Without Mount: 3.9 kg (8.6 lb) With Mount: 3.99 kg (8.8 lb) |
| Enclosure Characteristics |
SGCC Steel |
| Hardware | |
| Total Non-Blocking Line Rate |
52 Gbps |
| Max. Power Consumption |
40W |
| Forwarding Rate |
77.376 Mpps |
| Power Method |
Universal AC Input: 100-240VAC, 50/60 Hz |
| Power Supply |
AC/DC, Internal, 60W |
| Supported Voltage Range |
100 - 240VAC |
| Networking Interfaces |
(48) 10/100/1000 Mbps Ethernet RJ45 Ports (4) 1 Gbps SFP Ports |
| Management Interface |
Ethernet In-Band |
| Modes |
SMB Layer 2 Gigabit Ethernet Switch |
| Operating Temperature |
-15 to 40° C (5 to 104° F) |
| Operating Humidity |
10 - 90% Noncondensing |
| Certifications |
CE, FCC, IC |
| LEDs | |
| System |
(1) Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted |
| Ethernet |
Green: 1G, Amber: 10/100 Mbps |
| SFP |
Green: 1G |
| Gyártó | UBIQUITI |
| Menedzselhető | Van |
| Menedzselhetőség | Web |
| Port típusa | 1Gb Réz |
| Portok száma | 48 |
| Rack-be szerelhető | Van |
| SFP port | 4 |
| Switch típus | Fixed port |
